L-series with over 200bhp already created... - Page 15 - MG-Rover.org Forums
 1Likes
Reply

LinkBack Thread Tools Rating: Thread Rating: 5 votes, 5.00 average. Display Modes
post #281 of 297 (permalink) Old 09-04-2014, 14:44
Registered User

Join Date: Dec 2008
Location: Moscow, Russia
Car: Rover 25
Posts: 165
Quote:
Originally Posted by E_T_V View Post
Any chance of making me on
its not the problem to do one but deliver from russia ))! i don`t think you like to wait, and also you can do it youreself there is no any problems for do that, also for proper manifold it must be mocking up un engine and gearbox with turbo on it, i don`t have spare short engine and gearbox case for moking )!
Spiegelmann is offline
Sponsored Links
Advertisement

post #282 of 297 (permalink) Old 09-04-2014, 17:10
Registered User

Join Date: Dec 2008
Location: Moscow, Russia
Car: Rover 25
Posts: 165
Quote:
Originally Posted by pervavore View Post
Awesome rebuild Where from you get the bigger head of the pump ??
From the tractor engine, from 2000-2002 vp30 pump stays on john deer cummins 4 cyl!
Spiegelmann is offline
post #283 of 297 (permalink) Old 09-04-2014, 17:46
Registered User

Join Date: Aug 2010
Location: Rotherham
Car: R45 TD
Posts: 5,351
I've got a buttload of part numbers for the correct spinning 12mm heads - but they're not cheap new

As always, impressed with your progress Alexey!
Dastardly-Dan is offline

post #284 of 297 (permalink) Old 09-04-2014, 17:51
Registered User

Join Date: Dec 2008
Location: Moscow, Russia
Car: Rover 25
Posts: 165
Quote:
Originally Posted by pervavore View Post
Awesome never though of that but also the big Cummins run with vp30 so I will have a look. Did you get the head brand new or used?
Head is from engine. I've installed it own head. It runs about 106000 km, before rebuild
Spiegelmann is offline
post #285 of 297 (permalink) Old 09-04-2014, 17:52
Registered User

Join Date: Dec 2008
Location: Moscow, Russia
Car: Rover 25
Posts: 165
Quote:
Originally Posted by Dastardly-Dan View Post
As always, impressed with your progress Alexey!
Thanks Dan :-D
Spiegelmann is offline
post #286 of 297 (permalink) Old 10-04-2014, 22:13 Thread Starter
Registered User

Join Date: Apr 2007
Location: Bristol\Random hotels in Europe
Car: ZS+ 170TD
Posts: 4,834
Blog Entries: 8
I def think this needs to be split out by a mod into a seperate build thread!

Excellent work, really looking forward to seeing your final results - hope you don't find another weak point once all bolted together again and a few 1000 kms running!

Good luck with the rest of it
p_b82 is offline
post #287 of 297 (permalink) Old 11-04-2014, 04:51
Registered User

Join Date: Dec 2008
Location: Moscow, Russia
Car: Rover 25
Posts: 165
a few weak points where founded ))! anyway i fixed it, went for testdrive yesterday, but without full throttle, as i`m a bit worry, about crank bearings, so engine runns well, and very louding, thinking now maybe is it worth to install backbox and stronger, in russiapolice can`t stop you if you very loud ))!
Spiegelmann is offline
post #288 of 297 (permalink) Old 11-04-2014, 09:53
Registered User

Join Date: Dec 2008
Location: Moscow, Russia
Car: Rover 25
Posts: 165
Quote:
Originally Posted by pervavore View Post
Videos are welcome
not today, next week perhaps, just have a few problem with my health - stomach gastritis, hope next week will start installing lift pump in fuel tank
Spiegelmann is offline
post #289 of 297 (permalink) Old 02-10-2014, 08:25
Registered User

Join Date: Dec 2008
Location: Moscow, Russia
Car: Rover 25
Posts: 165
Hello guys! So got VNT controller instaled, thanks much for Reminguez aka Pervavore, without him i doubdt i can do something better. So here i some videos.

http://youtu.be/wTjpRdLvu44

http://youtu.be/WV7lv2uJzac

got a limp after 4000 guess my maf and boost are over in maps limit need some tune, and a worry news is got knocking sound in the top of CH like lifters or even a valves., thats last news
Spiegelmann is offline
post #290 of 297 (permalink) Old 02-10-2014, 20:10
Registered User

Join Date: Dec 2008
Car: ZS TD
Posts: 951
Thanks for the update, it looks very quick, power seems to come on all at once.
What is the specs now? You should update your build thread
ZS Phil is offline
post #291 of 297 (permalink) Old 02-10-2014, 21:08
Diesel Tuning Dude

Dakta's Avatar

Join Date: Jul 2007
Location: Wakefield
Car: 75 Tourer Conn SE & 45 TDi VNT
Posts: 17,815
Garages
Send a message via MSN to Dakta
did anything come of this 200bhp find?



Dieselpowered - file revisions ahead of the competition
Dakta is offline
post #292 of 297 (permalink) Old 03-10-2014, 05:04
Registered User

Join Date: Dec 2008
Location: Moscow, Russia
Car: Rover 25
Posts: 165
Quote:
Originally Posted by ZS Phil View Post
Thanks for the update, it looks very quick, power seems to come on all at once.
What is the specs now? You should update your build thread
nahh its not fast as im awaiting, its cutting at 4000 rpm, got more bugs )) going to paint now so next few months no interesting updates, final mapping after i finish all mechanical parts (suspension, brakes, strange engine knocking ))! And than run for dyno..
Spiegelmann is offline
post #293 of 297 (permalink) Old 03-10-2014, 05:06
Registered User

Join Date: Dec 2008
Location: Moscow, Russia
Car: Rover 25
Posts: 165
Quote:
Originally Posted by Dakta View Post
did anything come of this 200bhp find?
i`m very doubt about it even near 190 Kris ( anyway looking forward with hope ))!
Spiegelmann is offline
post #294 of 297 (permalink) Old 03-10-2014, 14:18
Registered User

Join Date: Nov 2008
Car: CityRover
Posts: 476
Nothing to thank will also play with the PID controller Hope to see a dyno when all other bugs are fixed and hope to see 300 bhp plus LOL
pervavore is offline
post #295 of 297 (permalink) Old 12-12-2014, 00:18
Registered User

Join Date: Sep 2008
Car: Rover 25
Posts: 74
Any news from this projecto???
Spiegelmann can you tell the part number for the 12mm head pump
ren.xx is offline
post #296 of 297 (permalink) Old 09-11-2015, 09:45
Registered User

Join Date: Dec 2008
Location: Moscow, Russia
Car: Rover 25
Posts: 165
new custom made nozzles 6x0.290 special for rover l-series



E_T_V likes this.
Spiegelmann is offline
post #297 of 297 (permalink) Old 14-02-2017, 13:33
Registered User

Join Date: Dec 2008
Location: Moscow, Russia
Car: Rover 25
Posts: 165
Hi ALL peaople so that is HOW to COOK VP30 superpump ))!

As some of you knows i done a few thousands km after build a 12mm pump and get a twice broken camplate cross, so here is the recipe:
- 12mm rotor 2 468 334 104(5) from cummins 3.9 isb i used 105 (it has ceramic washer instaed double copper washers on plunger heel) it used with original spring no preload needed u have to set proper K setting 5.6 mm


- next step is disassemble pump and drill fill port to incase pump



- use intank liftpump and pressure regulator with its own return fuel line back in the tank, i used petrol fuel pump from 25 petrol K series its direct fit. Addnig a fuel relay in PDC underbonnet and a wire throw original fuse in pdc so it all in oem connector direct fit. Also adding a inertia switch underbonnet to shut off.

- use black camplate cross 1 460 140 334 from freelander pump or vag doesnt matter dieselmeken says
its stronger than original


- to set K setting u need tool to remove Quantity solenoid


- and of corse u need huge nozzles that can flow that big amount of fuel the pump can deliver with no restriction i did custom ones with same spray geometry and pattern as oem

Cheers
Spiegelmann is offline
